SMT High Current Inductors

8 Series · 77 Part Numbers Export Category PDF

Inductance: 50 – 250 nH
DCR: 0.22 – 0.32 mΩ
Isat: 18 – 85 A
Idc: 42 – 50 A

Inductance: 100 – 310 nH
DCR: 0.3 mΩ
Isat: 16 – 65 A
Idc: 48 A

Inductance: 90 – 350 nH
DCR: 0.35 – 0.5 mΩ
Isat: 15 – 72 A
Idc: 29 – 40 A

Inductance: 120 – 770 nH
DCR: 0.2 mΩ
Isat: 12 – 100 A
Idc: 50 A

Inductance: 100 – 1,300 nH
DCR: 0.56 – 4.5 mΩ
Isat: 12 – 55 A
Idc: 14 – 40 A

Inductance: 100 – 7,200 nH
DCR: 0.5 – 12 mΩ
Isat: 7 – 75 A
Idc: 8 – 45 A

Inductance: 180 – 3,900 nH
DCR: 0.41 – 5.25 mΩ
Isat: 16 – 85 A
Idc: 16 – 45 A

Inductance: 210 – 330 nH
DCR: 0.58 mΩ
Isat: 31 – 45 A
Idc: 38 A
